ToneSpeak Dartford 1220 - 12" Guitar Speaker 20 Watt 8 Ohm

SKU: tonespeak-dart

Canadian Dollar Price:
Sale price$413.99
Stock:
In stock (4 units)

Description

Dartford 1220

Since the earliest days of electric guitar amplification, alnico magnets have shaped the warm, dynamic tones that define blues, rock, and jazz. The Dartford 1220 continues this tradition, offering players a vintage-inspired sound with modern reliability.

This 12-inch speaker pairs a powerful 34 oz. alnico magnet with a proprietary British paper cone, delivering warm, resonant mids, punchy lows, and a signature chime in the highs. With its naturally responsive and expressive character, the Dartford 1220 enhances the depth and detail of your playing, making it an essential upgrade for musicians seeking tonal perfection.

Key Features:

  • 12-inch (305 mm), 20-Watt power handling at 8 Ω impedance
  • 99 dB SPL sensitivity for rich projection
  • 34 oz. alnico ring magnet for vintage warmth and dynamics
  • 1.75-inch copper voice coil with a paper former for authentic tone
  • Full paper cone with proprietary edge doping for enhanced response

Crafted for those who crave classic tone and expressive articulation, the Dartford 1220 transforms your amplifier into a vehicle for timeless sound.





Nominal Diameter (in & mm) 12" (305 mm)
Nominal Impedance (Z) (Ω)
Rated Power IEC 60268-5 (W) 20
Program Power (W) 40
Magnet Weight (g) 964
Voice Coil Diameter (mm) 45
Sensitivity (dB SPL) 99
Frequency Range (Hz) 75 - 5000
Resonant Frequency (Fs) (Hz) +/- 15% 91
DC Resistance (Re) (Ω) 5.8
Voice Coil Inductance (Le) (mH) 0.32
Moving Mass (Mms) (gm) 30.17
Suspension Compliance (Cms) (mm/N) 0.1
Motor Force Factor (BL) (T•M) 9.66
Mechanical Q Factor (Qms) 18.78
Electrical Q Factor (Qes) 1.07
Total Q Factor (Qts) 1.01
Compliance Equivalent Volume (Vas) (L) 36.55
Surface Area of Diaphragm (Sd) (cm²) 502.7
Basket Type Stamped steel
Magnet Material Alnico
Cone Body Material Paper (Kurt Muller)
Cone Surround Material Paper (Kurt Muller)
Dust Cap Material Cloth
Spider Material Cotton
Voice Coil Wire Material Copper
Voice Coil Former Material Paper
Voice Coil Winding Style Single Layer
