With its robust steel-chassis, PULSE10, provides a rock-solid bass performance whether alone in a single speaker combo, in a 4x10 or even an 8x10 cab. Expect a tight, punchy low end with a warm mid-range that’s full of presence, bringing focus and articulation to your playing. This heavy-duty driver truly delivers bass you can feel as well as hear.
General Specifications
|
| Nominal diameter |
10", 254mm |
| Power rating |
200W |
| Nominal impedance |
8Ω |
| Sensitivity |
94dB |
| Magnet type |
Ferrite |
| Voice coil diameter |
2", 50.8mm |
| Coil material |
Copper |
| Cone material |
Kevlar loaded paper |
| Former material |
Polyimide |
| Surround material |
Cloth-sealed |
| Frequency range |
45-3500Hz |
| Xmax |
0.15", 4mm |
| Gap depth |
0.31", 8mm |
| Voice coil winding width |
0.62", 16mm |
Small Signal Parameters
|
| D |
0.21m/8.3in |
| Fs |
68Hz |
| Mms |
32.9g/1.16oz |
| Qms |
2.54 |
| Qes |
0.53 |
| Mmd |
29.26g/1.03oz |
| Qts |
0.44 |
| Re |
6.03Ω |
| Vas |
25.8lt/0.91cu.ft. |
| BI |
12.88Tm |
| Cms |
0.15mm/N |
| Rms |
5.79kg/s |
| Le (at 1kHz) |
0.92mH |
Mounting Information
|
| Cut-out diameter |
9", 229mm |
| Diameter |
10.1", 256mm |
| Mounting slot dimensions |
0.24x0.31", 6x8mm Ø |
| Mounting slot PCD |
9.6", 245mm |
| Number of mounting slots |
4 |
| Overall depth |
4.3", 110mm |
